M:R330
Compact stage. Powerful rotation.
The M:R330 is a compact, high-load revolving stage designed for smooth, precise and reliable rotational movement in live productions.
Featuring a 3250 mm diameter, a total load capacity of up to 3000 kg and a low-profile construction of just 200 mm, it delivers powerful performance without taking up unnecessary stage space.
Built for touring, the M:R330 features a modular construction for quick assembly, flexible flooring options and quiet operation, making it ideal for theatre, musicals, live entertainment and complex scenic transformations.
Key Features
3000 kg Load Capacity – High-load revolving stage designed to support heavy scenic elements and stage installations.
Flooring: Multiple surface options available.
Compact & Low-Profile Design – 3250 mm diameter with a construction height of just 200 mm, excluding flooring.
Smooth & Quiet Rotation – Controlled rotational movement at speeds up to 3.42 rpm.
Touring-Ready Construction – Modular sections designed for quick assembly, disassembly and transport.
Integrated Power & Data – Up to 63A three-phase power and fibre-optic data connections at centre stage.Dimensions & weight
Dimensions & weight
Disc Diameter: 3250 mm
Height: 200 mm (excluding flooring)
Total Load Capacity: 3000 kg
Distributed Load Capacity: 350 kg/m²
Maximum Rotation Speed: 3.42 rpm
Touring Carts: 1
-
With a diameter of 3,250 mm and a low build height of just 200 mm without flooring, the M:R330 integrates easily into stage and scenic designs.
-
Designed for demanding productions, the revolve supports loads of up to 350 kg/m² and a total load capacity of 3,000 kg.
-
The M:R330 rotates at up to 3.42 rpm, delivering smooth and controlled movement for both subtle transitions and dynamic show cues.
-
63A three-phase power and fibre optic connections can be routed through the centre of the revolve, keeping equipment connected while the platform is moving.
-
Built in modular sections for efficient transport, handling and installation, making it well suited for touring productions and changing venues.
-
The M can be operated with professional automation systems including Kinesys Elevation 1+ and MOVEKET V-Motion for precise and repeatable control.
BUILT TO MOVE. BUILT TO TOUR.
